The Daikin OTERRA Series 24000 BTU 21 SEER2 Ductless Mini Split Heat Pump uses advanced inverter technology to maintain stable temperatures and save up to 30% on energy. With a 21 SEER2 rating, 12 EER2, and 9.1 HSPF2, it offers efficient cooling and heating in a quiet, easy-to-install design.
Standard Features:
- Inverter Swing Compressor
- Precharged for up to 32.8 ft of Liquid Line
- Self Diagnostics
- Energy Saving Function / Dry Function / Powerful Operation
- Simple Maintenance
- Anti-Corrosion Treatment on Outdoor Heat Exchanger
- Wireless Backlit, IR Remote Controller
- Indoor Unit Quiet Operation
- Auto Restart after Power Failure
- Max Piping (09/12 MBH): 65.625' Length, 49.25' Height
- Max Piping (18/24 MBH): 98.5' Length, 65.625' Height
Perfect for single-zone applications, its wall-mounted design provides a sleek and space-saving installation. With a standard operating range of
- Heating: 5°F to 64.4°F
- Cooling: 50°F to 114.8°F
- LOW AMBIENT COOLING: Cutting Jumper 6 (J6) on 09/12K and (J4) on 18/24K expands operation to 5°F
It delivers reliable temperature control in various climates.
-
AHRI 213895722 Condenser Model Number RXF24AXVJU Dimension H 27.41 x W 36.63 x D 13.81 in Unit Weight 101 lb Tonnage 2 SEER2 18 EER2 12 HSPF2 9.1 Cooling Capacity Nominal 24,000 Btu/H Heating Capacity Nominal 24,000 Btu/H Max Fuse Size 20 A Voltage 208/230 V Cooling Sound Pressure 55 dBA Heating Sound Pressure 55 dBA Liquid Connection 1/4" Suction Fitting 5/8" Max Pipe Length 98.5 ft Refrigerant R-32 Coil Model Number FTXF24AXVJU Dimension H 11.7 x W 39.56 x D 10.75 in Unit Weight 30.5 lb Cooling Sound Pressure 53 dBA Heating Sound Pressure 53 dBA Style Wall Mounted -
-
