Model: GLXS4BA1810 / CHPTA2426B3 / GR9S800603BN

Goodman 1.5 Ton 15.2 SEER2 AC & 80% AFUE 60K BTU Gas Furnace System, R32 Refrigerant - Horizontal

Goodman 1.5 Ton 15.2 SEER2 AC & 80% AFUE 60K BTU Gas Furnace System, R32 Refrigerant - Horizontal

Free Liftgate Shipping 10 Year parts warranty W/ online registration

AC & furnace combo: Pre-charged AC to 15ft w/ 17.5" furnace. Natural gas/propane (kit req).
Regular price $3,875.00
Regular price Sale price $3,875.00
Sale Sold out
Guaranteed Safe Checkout

Free express shipping
Ships in 1-2 business days
60 Days return policy
Expert Support

Price Match Request

Found a lower price on equipment? Let us know and we'll match it (Exclude below-cost items).

Product
Goodman 1.5 Ton 15.2 SEER2 AC & 80% AFUE 60K BTU Gas Furnace System, R32 Refrigerant - Horizontal
Our Price
$3,875.00

Got a question? Talk with our experts anytime

Call Us at 866-718-1799

CHAT WITH US EMAIL US

Product Details

The Goodman 1.5 Ton 15.2 SEER2 AC & 80% AFUE 60K BTU Gas Furnace System (Horizontal) is a high-performing, energy-efficient solution for heating and cooling needs.

Key Features of the Goodman 1.5 Ton 15.2 SEER2 AC:

  • Energy Efficiency: To begin with, equipped with an efficient compressor and pre-charged tubing for up to 15 feet.
  • Durability: Features copper tubing with enhanced aluminum fin coils and a factory-installed filter drier.
  • Certified Quality: Moreover, AHRI Certified and ETL Listed for compliance with industry standards.
  • User-Friendly: Includes sweat connection service valves, high-pressure switch, and extended-life capacitors.

Evaporator Coil (CHPTA2426B3):

  • R-32 Compatibility: Optimized for R-32 refrigerant with factory-installed thermal expansion valves.
  • Compact Design: A 21-inch depth allows for easier installation in tight spaces.
  • Long-Lasting Build: Rust-resistant, UV-protected drain pan and galvanized finish ensure durability.
  • Certified Performance: In addition, AHRI Certified and ETL Listed for reliability.

Gas Furnace (GR9S800603BN):

  • Efficient Heating: Goodman 1.5 Ton 15.2 SEER2 Provides quiet, economical heating with an 80% AFUE rating.
  • Advanced Features: Includes a self-diagnostic control board, durable igniter, and support for electronic air cleaners and humidifiers.
  • Installation Flexibility: Furthermore, it works with two-stage or single-stage thermostats for seamless setup.
  • Environmentally Friendly: Additionally, low NOx emissions and tax credit eligibility.

Cabinet Features of the Goodman 1.5 Ton 15.2 SEER2:

  • Sturdy Design: Heavy-gauge steel cabinet with a durable baked-enamel finish.
  • Flexible Installation: Also, it supports multi-position setups, including horizontal, upflow, and downflow.
  • Convenience: Goodman 1.5 Ton 15.2 SEER2 offers easy access for gas and electrical service and minimal air leakage (≤2%).

In summary, the Goodman 1.5 Ton 15.2 SEER2 AC & 80% AFUE 60K BTU Gas Furnace System combines energy efficiency, reliability, and easy installation, making it a top-tier choice for residential heating and cooling systems

Specifications

AHRI Reference 215214605
AC Model Number GLXS4BA1810
SEER 2 14.3
Tonnage 1.5
Unit Height x Width x Depth 27 x 26 x 26 in
Unit Weight 69 lb
Cooling Capacity Nominal 18,000 Btu/H
Max Overcurrent Protection 15A
Power Voltage 208/230 V
Compressor Stages Single Stage
Compressor Type Rotary
Refrigerant Type R-32
Evaporator Coil Model Number CHPTA2426B3
Tonnage 1.5 - 2
Unit Height x Width x Depth 17.5 x 26 x 21 in
Cased/Uncased Cased
Coil Application Horizontal
Refrigerant Type R-32
Gas Furnace Model Number GR9S800603BN
Height x Width x Depth 33-3/8 x 17.5 x 28 in
Weight 100 lb
AFEU 80%
Configuration Upflow/Horizontal
BtuH Input 60,000
BtuH Output 48,000
Tons 3
CFM 1,200
Min. Circuit Amps 7.7
Motor Type ECM
Stages Single
LoNox No
