The Goodman 3.5 Ton 15.2 SEER2 AC & 96% AFUE 80K BTU Gas Furnace System - Upflow, R32 (GLXS4BA4210) combines high efficiency, reliability, and modern design to ensure year-round comfort for medium-sized homes.
Key Features of the Goodman 3.5 Ton 15.2 SEER2 AC:
- Energy-Efficient Compressor: Reduces energy costs while maintaining reliable cooling.
- Pre-Charged Refrigerant: Ready for up to 15 feet of tubing, simplifying installation.
- High-Durability Coils: Copper tubing with enhanced aluminum fins ensures effective heat transfer.
- Integrated Safety Measures: Factory-installed filter drier and high-pressure switch for added protection.
- Extended Component Life: Long-lasting capacitors and enclosed contactor with lug connections.
- Certifications: AHRI Certified and ETL Listed for performance and safety assurance.
Cabinet Features of the Goodman 3.5 Ton 15.2 SEER2:
- Rust-Resistant Finish: Attractive gray powder coat with 500-hour salt-spray approval.
- Enhanced Airflow: Venturi design for increased velocity and efficiency.
- Weather-Resistant: Meets 2023 Florida Building Code for hurricane wind resistance.
- Ease of Maintenance: Single-panel access to controls and top maintenance features.
- Flexible Installation: Furthermore, it supports upflow, horizontal left, and horizontal right configurations.
- Versatile Venting: Compatible with direct vent (2-pipe) and non-direct vent (1-pipe) systems.
- Durable Build: Heavy-gauge steel cabinet with a resilient finish.
- Low Air Leakage: Qleak ≤ 2% ensures efficiency and compliance with industry standards.
Evaporator Coil - CAPTA4230C3:
- All-Aluminum Coil: Also, it offers long-term durability and compatibility with R-32 refrigerant.
- Compact Design: Additionally, 21-inch depth allows for easier attic installations.
- Thermal Efficiency: Foil-faced insulation minimizes condensation and maintains efficiency.
- Enhanced Drainage System: UV-resistant thermoplastic drain pan resists rust and reduces water retention.
- Ease of Service: Drain pan rails allow for simple removal and repositioning.
- Certifications: AHRI Certified and ETL Listed for safety and reliability.
Gas Furnace - GR9S960805CN:
- 96% AFUE Efficiency: Goodman 3.5 Ton 15.2 SEER2 provides exceptional heating performance while minimizing energy costs.
- Reliable Ignition: Durable igniter with extended lifespan.
- Environmentally Friendly: Low NOx emissions reduce environmental impact.
- Advanced Diagnostics: Self-diagnostic control board with constant memory for simplified troubleshooting.
- Tax Credit Eligible: Meets standards for energy-efficiency incentives.
- Quiet Operation: Lastly, it is designed for efficient, low-noise circulation.
Therefore, the Goodman 3.5 Ton 15.2 SEER2 AC & 96% AFUE 80K BTU Gas Furnace System is engineered to deliver reliable and efficient heating and cooling. With advanced components, robust construction, and energy-efficient performance, this system is an excellent choice for homeowners seeking comfort, reliability, and value
-
AHRI Reference 214859965 AC Model Number GLXS4BA4210 SEER 2 14.3 Tonnage 3.5 Unit Height x Width x Depth 35.75 x 35.5 x 35.5 in Unit Weight 210 lb Cooling Capacity Nominal 42,000 Btu/H Power Voltage 208/230 V Phase Single Motor Type PSC Min Circuit Amps 18.95 Max Fuse Size 30 Liquid Connection 3/8" Suction Fitting 1-1/8" Refrigerant Type R-32 Evaporator Coil Model Number CAPTA4230C3 Tonnage 3.5 Unit Height x Width x Depth 30 x 21 x 21 in Unit Weight 66 lb Liquid Connection 3/8" Suction Fitting 7/8" Coil Type Cased Configuration Upflow/Downflow Metering Device TXV Refrigerant Type R-32 Gas Furnace Model Number GR9S960805CN Height x Width x Depth 34.5 x 21 x 28.75 in Weight 142 lb AFEU 96% Configuration Upflow/Horizontal BtuH Input 80,000 BtuH Output 77,600 Tons 3 - 5 CFM 2,000 Min. Circuit Amps 16.7 Vent Size 2" - 3" Motor Type ECM Stages Single LoNox No -
-
