Model: GLXS3BN3610 / CAPTA3626B3
Goodman 3 Ton 13.4 SEER2 R32 Air Conditioner & 17.5" Vertical Cased Coil
Goodman 3 Ton 13.4 SEER2 R32 Air Conditioner & 17.5" Vertical Cased Coil

Couldn't load pickup availability
Product Details
The 3 Ton AC Goodman 13.4 SEER2 & 17.5" Vertical Cased Coil offers efficient, eco-friendly cooling for your home or business. Designed for easy installation and long-lasting performance, this system delivers reliable comfort.
3 Ton AC Goodman - GLXS3BN3610 Features:
- Energy-Efficient Compressor for optimal performance and energy savings.
- Fully Charged for 15' of Tubing simplifying installation.
- Durable Coil Design with copper tubing and enhanced aluminum fins.
- Factory-Installed Filter Drier to protect against moisture and contaminants.
- High-Pressure Switch and Extended-Life Capacitors for durability.
- AHRI Certified and ETL Listed for safety and performance assurance.
Cabinet Features:
- 3 Ton AC Coil-Grille-Style Top Design for better airflow and UL compliance.
- Architectural Gray Finish with 500-hour salt-spray approval.
- Steel Louver Coil Guard and Easy Maintenance Access.
- Single-Panel Access for field-installed accessories.
3 Ton Coil - CAPTA3626B3 Features:
- All-Aluminum Coil for corrosion resistance and efficient heat transfer.
- R-32 Optimized refrigerant compatibility for improved performance.
- Factory-Installed Thermal Expansion Valves for cooling and heat pump applications.
- Vertical Application with 21" Depth for easier attic installation.
The 3 Ton AC Goodman 13.4 SEER2 & 17.5" Vertical Cased Coil combines energy efficiency, eco-friendly refrigerant, and durability to deliver dependable, long-lasting cooling.
Specifications
AHRI | 215271990 |
---|---|
AC Model Number | GLXS3BN3610 |
SEER2 | 13.4 |
Tons | 3 |
BTU | 36,000 |
Volts | 208/230 |
Phase | Single |
Motor Type | PSC |
Min. Circuit Amps | 17.5 |
Max Fuse Size | 30 |
Liquid Connection | 3/8" |
Suction Fitting | 7/8" |
Refrigerant | R-32 |
Width | 26" |
Height | 32.5" |
Depth | 26" |
Weight | 136 |
Evaporator Coil Model Number | CAPTA3626B3 |
Unit Depth | 21 in |
Unit Height | 26 in |
Unit Width | 17.5 in |
Cased/Uncased | Cased |
Warranty & Shipping
Warranty
Enjoy a 10-year limited parts warranty when your unit is registered within 60 days of installation. The installation must be completed by a properly certified professional adhering to city, state and federal laws.
Processing Time
We process and ship orders Monday through Friday. Orders placed by 12 p.m. EST on these days are usually shipped within 1 to 2 business days and arrive within 3 to 5 business days. Orders placed on weekends will start processing the next business day. Some items may be backordered, leading to possible delays. Shipping times begin once the order leaves our warehouse. While we aim for timely delivery, delays by freight or ground carriers are beyond our control. FREE Life Gate.
Equipment Arrival
Shipping times are not guaranteed and may vary by address. Upon delivery, inspect each item and match the count with the delivery receipt before signing. Report any missing or incorrect items within 24 hours; claims reported after this period may be denied. Inspect items for damage in front of the driver before signing the receipt. Note any issues like dents or scratches clearly on the receipt or reject the shipment if damaged.
Making Notes on the Delivery Receipt
If the items and quantity on the delivery receipt match what you received and are undamaged, sign and mark the receipt as "Clear."
If items or boxes are missing, mark the receipt as " Short" and list the missing items. We will ship replacements to you at no extra charge. If the strip wrap is torn or replaced, mark the receipt as "Wrap Broken."
How Do I Handle a Damaged Shipment?
If any items are damaged, mark the receipt as "Damaged," specifying the items and the nature of the damage. Refuse only the damaged items, keep and sign for the rest, and clearly note the refused items on the receipt. Contact our Customer Service to report which items were refused and which were accepted. We will ship replacements once our Shipping Department confirms the damage with the Freight LTL Company. If you sign for the delivery but later discover damage, you are responsible for it. You will need to contact the Freight LTL Company’s claims department directly to file a claim.
Documents
- //hvactotal.com/cdn/shop/files/GLXS3 Spec Sheet
- //hvactotal.com/cdn/shop/files/GLXS3 Installation Manual
- //hvactotal.com/cdn/shop/files/GLXS3 Warranty Guide
- //hvactotal.com/cdn/shop/files/Vertical Coil Installation
- //hvactotal.com/cdn/shop/files/CAPTA Coils repair parts
- //hvactotal.com/cdn/shop/files/A2L Sensor Dragonfly Installation
