The Goodman 4 Ton 13.5 SEER2 AC & 80% AFUE 120K BTU Gas Furnace System (GLXS3BN4810) is an energy-efficient and durable heating and cooling solution. Designed for upflow installations, it ensures reliable year-round performance and comfort.
Key Features of the Goodman 4 Ton 13.5 SEER2 AC:
- Energy-Efficient Compressor: Delivers powerful cooling while minimizing energy consumption.
- Pre-Charged Refrigerant: Goodman 4 Ton 13.5 SEER2 simplifies installation with up to 15 feet of pre-charged tubing.
- Advanced Coil Technology: Features copper tubes and 5mm aluminum fins for enhanced heat transfer.
- Durable Components: Also, it includes factory-installed filter drier, extended-life capacitors, and an enclosed contactor for reliable performance.
- Certifications: AHRI Certified and ETL Listed for safety and quality.
- Cabinet Design: Features a venturi for increased airflow, grille-style top compliant with UL 60335-2-40, and a durable powder-paint finish.
Evaporator Coil - CAPTA6030D3:
- All-Aluminum Construction: Optimized for R-32 refrigerant for long-lasting performance.
- Factory-Installed Valves: Thermal expansion valves for cooling and heat pump applications.
- Compact Design: 21” depth and single front access panel for easy attic access and maintenance.
- Enhanced Durability: In addition, it includes a rust-resistant, UV-protected thermoplastic drain pan and galvanized finish.
Gas Furnace - GR9S801205DN:
- High Reliability: Goodman 4 Ton 13.5 SEER2 ensures dependable heating with faster condensate drainage and no water leakage.
- Quiet and Economical: Moreover, it operates quietly with reduced NOx emissions and energy-efficient heating.
- Self-Diagnostics: Furthermore, it features a self-diagnostic control board with constant memory for easier troubleshooting.
- Versatile Installation Options: Also, it supports upflow, horizontal left/right setups, and direct or non-direct venting.
- Convenient Connectivity: Compatible with electronic air cleaners and humidifiers to enhance indoor air quality.
- Cabinet Design: Fully insulated heat exchanger and blower section with provisions for side or bottom return air applications.
Therefore, the Goodman 4 Ton 13.5 SEER2 AC & 80% AFUE 120K BTU Gas Furnace System delivers energy-efficient performance, advanced features, and versatile installation options. Its durable design ensures long-term comfort and reliability for your home.
-
AHRI Reference 215277708 AC Model Number GLXS3BN4810 SEER 2 13.4 Tonnage 4 Unit Height x Width x Depth 39.5 x 29 x 29 in Unit Weight 188 lb Cooling Capacity Nominal 48,000 Btu/H Max Overcurrent Protection 40A Power Voltage 208/230 V Compressor Stages Single Stage Compressor Type Scroll Refrigerant Type R-32 Evaporator Coil Model Number CAPTA6030D3 Tonnage 5 Unit Height x Width x Depth 30 x 24.5 x 21 in Cased/Uncased Cased Coil Application Upflow/Downflow Refrigerant Type R-32 Gas Furnace Model Number GR9S801205DN Height x Width x Depth 33-3/8 x 24.5 x 28 in Weight 132 lb AFEU 80% Configuration Upflow/Horizontal BtuH Input 120,000 BtuH Output 96,000 Tons 5 CFM 2,000 Min. Circuit Amps 11.3 Vent Size 4" Motor Type ECM Stages Single LoNox No -
-
